100L 150L 200L 300L Industrial Explosion Proof Jacketed Stainless Steel Reactor

LEXSR-100L/ LEXSR-150L/ LEXSR-200L/ LEXSR-300L

The overall structure of LABOAO large industrial explosion proof chemical stainless steel double layer reactor is made of stainless steel S304 or S316L, which is highly resistant to corrosion, high temperature, and high pressure, has higher tolerance, has a stronger surface, is not easily damaged, and is easy to clean and maintain. Mainly used in industrial-scale chemical production, pharmaceuticals, food processing, petrochemicals and high-temperature and high-pressure reactions.

Request Quotation Chat Now

WhatsApp Chat
WeChat Chat

Download

SPECIFICATIONS

Model	LEXSR-100L			LEXSR-150L		LEXSR-200L			LEXSR-300L
Kettle volume	100L			150L		200L			300L
Mezzanine volume	20L			40L		45L			50L
Voltage/frequency					220V/50 Hz
Reaction temperature					-120~260℃
Vacuum degree					-0.098Mpa
Stirring speed					0-460rpm
Power			370W				750W
Sealed form					SUS304 ceramic combination mechanical seal
Number of cauldron lid openings					Eight ports (optional)
Material					SUS316L/SUS304
Sight glass		Φ89			Φ159			Φ200
Feeding port		Φ59			Φ159			Φ200
Temperature measuring hole			50.5 chuck/Φ12 temperature measuring tube				50.5 quick opening
Drop hole			50.5 chuck/2000ml funnel				50.5 quick opening
Distillation hole					50.5 chuck/Φ38 return port
Pressure gauge					50.5 chuck/± integrated pressure gauge
Impeller					SUS316L propeller mixing paddle
Condenser					Vertical high-efficiency double reflux condenser tube
Exhaust					2-point exhaust valve
Bottom valve			Φ35/50.5 chuck				Φ51/64 chuck
Overall dimensions	10506902350mm			7307302400mm		8008002630mm			100010001950mm
Optional(Additional fee)					Explosion-proof whole machine/electric heating/Total 316L/collection tank/mobile frame /spraying PTFE

6 Good Reasons To Choose LABOAO 100L 150L 200L 300L Industrial Explosion Proof Jacketed Stainless Steel Reactor

Frequency conversion speed regulation, AC induction motor. The speed is constant, no brushes, no sparks, safe and stable, and can work continuously.
The entire set of instruments is made of SUS316L/SUS304 stainless steel, which has good chemical and physical properties.
The mezzanine interface is connected with hot oil for circulation and heating reaction can be carried out, and the refrigerant liquid is connected with it for low-temperature reaction.
It can react at room temperature, and the reaction heat can be quickly taken away by running tap water on it.
The lower discharge port uses a stainless steel ball valve. There is no dead space in the container and it is removable to facilitate the discharge of solid materials.
Eight-port reactor cover, extra-large port design for easy cleaning, standard port socket for optional assembly of reflux and distillation synthesis devices.
