200L Double Layer Stainless Steel Industrial Chemical Reactor
200L Double Layer Stainless Steel Industrial Chemical Reactor

200L Double Layer Stainless Steel Industrial Chemical Reactor

LSR-200L
The overall structure of LABOAO 200L large industrial chemical stainless steel double layer reactor is made of stainless steel S304 or S316L, which is highly resistant to corrosion, high temperature, and high pressure, has higher tolerance, has a stronger surface, is not easily damaged, and is easy to clean and maintain. Mainly used in industrial-scale chemical production, pharmaceuticals, food processing, petrochemicals and high-temperature and high-pressure reactions.
Request QuotationChat Now
  • Whatsapp

    WhatsApp Chat

  • WeChat

    WeChat Chat

Download

SPECIFICATIONS

Model

LSR-200L

Kettle   volume

200L

Mezzanine   volume

45L

Voltage/frequency

220V/50   Hz

Reaction   temperature

-120~260℃

Pressure

-0.1~0.3Mpa

Stirring   speed

0-460rpm

Power

400W

Sealed   form

Stainless   steel graphite combination mechanical seal

Number   of cauldron lid openings

Eight   ports (optional)

Material

SUS316L/SUS304

Sight   glass

Φ159

Feeding   port

Φ159

Temperature   measuring hole

50.5   chuck

Distillation   hole

50.5   chuck

Drop   hole

50.5   chuck

Pressure   gauge

50.5   chuck/± integrated pressure gauge

Impeller

SUS316L   propeller mixing paddle

Condenser

Φ108/length 600mm

Exhaust

2-point   exhaust valve

Bottom   valve

Φ51/61   chuck

Overall   dimensions

950*950*2250mm

Weight

156kg

Optional(Additional   fee)

Explosion-proof   whole machine/

electric   heating/Total 316L/collection tank/

mobile   frame /spraying PTFE

6 Good Reasons To Choose LABOAO 200L Double Layer Stainless Steel Industrial Chemical Reactor
