Rotary evaporator is the necessary basic instrument for chemical industry, medicine industry, institutions of higher learning and scientific research laboratory and other units, it is the main means for manufacturing and analyzing experiments when they do extraction and concentration.
Motor has the function of 10-120 RPM stepless speed regulation and automatic lifting , revolving consists of a set of stable and reliable micro motor, speed motor and integrated circuit control device. In the role of electronic speed, it can rotating steadily in 10-120 RPM range, it has reached the advanced level at home and abroad. 1. Quick and easy lifting mechanism. 2. Evaporator along the horizontal direction can lean in 0-45 ℃ arbitrarily. 3. Vertical condensation system of high rate of evaporation. 4. Vacuum sealing way. 5. Automatic control temperature digital display. Model LRE-52A Voltage/Frequency 220V/50HZ Whole power 1030W Rotary power 30W Heating power 1000W Vacuum degree 0.0098Mpa Rotary flask volume Eggplant shape 1L,Φ131mm/24# standard port Receiving flask volume Round shape 0.5L,Φ105mm/24#standard port Rotary speed 0-120rpm/min Temp.cotrolling range room temperature -99℃ Temp. accuracy ±1℃ Hosting lifting distance 150mm Condenser size Φ85*450H(mm) Condensation area 0.17㎡ Four-way bottle diameter Upper with 29# standard port, down with 24# standard plug, left with 19# standard port, right with 24# standard plug Air guide bottle Charging valve 19# standard plug valve, feed nozzle(pagoda-shape connectors),outer diameter 10mm Vacuum suction nozzle 29# standard plug valve, vacuum nozzle(pagoda-shape connectors), outer diameter 10mm Condensing coil in and out circuation nozzle Pagoda-shape connectors, outer diameter 12mm Pot bravery size Φ220*120H(mm) about 4.5L，3.5kg Overall dimensions (W*L*H) 640*430*(860-1010)mm Net weight 15kg Packing dimensions 600*460*470mm, 0.13m³ Packing weight 18.5kgFEATURES
SPECIFICATIONS
Upper with 29#standard port and equipped with glass exhaustor, down with 29# standard plug
