Rotary evaporator is the necessary basic instrument for chemical industry, medicine industry, institutions of higher learning and scientific research laboratory and other units, it is the main means for manufacturing and analyzing experiments when they do extraction and concentration.
1. The parts in contact with materials are all made of high borosilicate glass (expansion coefficient 3.3) and polytetrafluoroethylene materials, which are stable in performance and difficult to chemically react with materials. 2. The main frame is made of cold plate anti-corrosion spray + aluminum alloy material, and the pot is made of stainless steel. 3. The sealing system adopts PTFE + fluorine rubber compound combination seal. 4. The vacuum pressure gauge displays real-time vacuum and the pointer displays. 5. The piston-type feeding valve is sleeved with the PTFE extension tube, which can continuously feed to the evaporating flask under vacuum. 6. One-piece condenser, upright double-layer serpentine coil. 7. Rotating and heating power switch control, tilt button (ON-OFF) 8. Electronic stepless speed regulation, fine-tuning by twisting, digital display of speed. 9. Digital display of temperature of constant temperature bath, K-type sensor at the bottom of the pot + stainless steel probe. 10. The hand wheel of the bath pot is raised and lowered, rotating and heating double fuses for safety protection. Model LRE-301 Voltage/Frequency 220V/50HZ Whole power 2040W Rotary power 40W Heating power 2000W Vacuum degree 0.0098Mpa Rotary flask volume 3L,Φ195mm/Φ50 Flange port Receiving flask volume 2L,Φ166mm/35#ball mill port Rotary speed 0-120rpm/min Temp.cotrolling range room temperature -180℃ Temp. accuracy ±1℃ Flask lifting distance 200mm Condenser size Φ100*530H(mm) ,down 35# ball mill port Condensation area 0.26㎡ Charging valve 19# standard plug valve, feed nozzle(pagoda-shape connectors),outer diameter 10mm Vacuum suction nozzle Pagoda-shape connectors, outer diameter 10mm Condensing coil in and out circuation nozzle Pagoda-shape connectors, outer diameter 12mm Pot bravery size Φ265*160H(mm) about 8.8L，7.3kg Overall dimensions (W*L*H) 740*330*970mm Net weight 23kg Packing dimensions 990*620*470mm 0.29m³ Packing weight 40kgFEATURES
SPECIFICATIONS
