SPECIFICATIONS
Model | DLSB-5/10 | DLSB-5/20 | DLSB-5/30 | DLSB-5/40 | DLSB-5/60 | DLSB-5/80 | DLSB-5/120 |
Volume | 5L | ||||||
Min temperature | -15℃ | -24℃ | -33℃ | -42℃ | -62℃ | -82℃ | -123℃ |
Cooling capacity | 1328-319W | 1328-319W | 2733-627W | 2036-602W | 2036-330W | 2036-180W | 3888-160W |
Flow capacity | 20L/min | ||||||
Head | 4-6M | ||||||
Temperature range | -10℃ | -20℃ | -30℃ | -40℃ | -60℃ | -80℃ | -120℃ |
Temperature accuracy | ±0.2 | ||||||
Voltage | 220V/380V | ||||||
Working Temperature | 25℃ | ||||||
Working Humidity | (60-80)% ventilation | ||||||
Size(L*W*H) (mm) | 500*370*540 | 500*370*540 | 545*370*540 | 600*410*670 | 680*500*780 | 700*620*900 | 950*710*940 |
Model | DLSB-10/10 | DLSB-10/20 | DLSB-10/30 | DLSB-10/40 | DLSB-10/60 | DLSB-10/80 | DLSB-10/120 |
Volume | 10L | ||||||
Min temperature | -14℃ | -28℃ | -42℃ | -62℃ | -82℃ | -122℃ | -124℃ |
Cooling capacity | 1894-884W | 2733-813W | 2036-1022W | 2628-748W | 3679-510W | 3679-510W | 4997-120W |
Flow capacity | 20L/min | ||||||
Head | 4-6M | ||||||
Temperature range | -10℃ | -20℃ | -30℃ | -40℃ | -60℃ | -80℃ | -120℃ |
Temperature accuracy | ±0.2 | ||||||
Voltage | 220V/380V | ||||||
Working Temperature | 25℃ | ||||||
Working Humidity | (60-80)% ventilation | ||||||
Size(L*W*H) (mm) | 500*400*650 | 500*420*680 | 500*420*680 | 500*420*680 | 730*660*880 | 880*670*900 | 900*700*900 |
Model | DLSB-20/20 | DLSB-20/30 | DLSB-20/40 | DLSB-20/60 | DLSB-20/80 | DLSB-20/120 |
Volume | 20L | |||||
Min temperature | -33℃ | -42℃ | -62℃ | -82℃ | -122℃ | -124℃ |
Cooling capacity | 3255-990W | 2682-1350W | 3809-989W | 4997-510W | 7828-230W | 7828-160W |
Flow capacity | 20L/min | |||||
Head | 4-6M | |||||
Temperature range | -20℃ | -30℃ | -40℃ | -60℃ | -80℃ | -120℃ |
Temperature accuracy | ±0.2 | |||||
Voltage | 380V | |||||
Working Temperature | 25℃ | |||||
Working Humidity | (60-80)% ventilation | |||||
Size(L*W*H) (mm) | 500*450*780 | 500*450*780 | 560*440*888 | 850*700*980 | 880*700*1000 | 1050*800*1000 |
Model | DLSB-30/20 | DLSB-30/30 | DLSB-30/40 | DLSB-30/60 | DLSB-30/80 | DLSB-30/120 |
Volume | 30L | |||||
Min temperature | -32℃ | -42℃ | -62℃ | -82℃ | -122℃ | -124℃ |
Cooling capacity | 6249-1825W | 3809-1801W | 4829-1140W | 4997-160W | 7828-180W | 10364-210W |
Flow capacity | 20L/min | |||||
Head | 4-6M | |||||
Temperature range | -20℃ | -30℃ | -40℃ | -60℃ | -80℃ | -120℃ |
Temperature accuracy | ±0.2 | |||||
Voltage | 380V | |||||
Working Temperature | 25℃ | |||||
Working Humidity | (60-80)% ventilation | |||||
Size(L*W*H) (mm) | 610*520*950 | 600*500*950 | 650*580*950 | 800*620*1000 | 800*620*1000 | 1150*850*1100 |
