SPECIFICATIONS
Model | DLSB-20EX/20 | DLSB-20EX/30 | DLSB-20EX/40 | DLSB-20EX/60 | DLSB-20EX/80 | DLSB-20EX/120 |
Volume | 20L | |||||
Min temperature | -33℃ | -42℃ | -62℃ | -82℃ | -122℃ | -124℃ |
Cooling capacity | 3255-990W | 2682-1350W | 3809-989W | 4997-510W | 7828-230W | 7828-160W |
Flow capacity | 20L/min | |||||
Head | 4-6M | |||||
Temperature range | -20℃ | -30℃ | -40℃ | -60℃ | -80℃ | -120℃ |
Temperature accuracy | ±0.2 | |||||
Voltage | 380V | |||||
Working Temperature | 25℃ | |||||
Working Humidity | (60-80)% ventilation | |||||
Size(L*W*H) (mm) | 500*450*780 | 500*450*780 | 560*440*888 | 850*700*980 | 880*700*1000 | 1050*800*1000 |
Model | DLSB-30EX/20 | DLSB-30EX/30 | DLSB-30EX/40 | DLSB-30EX/60 | DLSB-30EX/80 | DLSB-30EX/120 |
Volume | 30L | |||||
Min temperature | -32℃ | -42℃ | -62℃ | -82℃ | -122℃ | -124℃ |
Cooling capacity | 6249-1825W | 3809-1801W | 4829-1140W | 4997-160W | 7828-180W | 10364-210W |
Flow capacity | 20L/min | |||||
Head | 4-6M | |||||
Temperature range | -20℃ | -30℃ | -40℃ | -60℃ | -80℃ | -120℃ |
Temperature accuracy | ±0.2 | |||||
Voltage | 380V | |||||
Working Temperature | 25℃ | |||||
Working Humidity | (60-80)% ventilation | |||||
Size(L*W*H) (mm) | 610*520*950 | 600*500*950 | 650*580*950 | 800*620*1000 | 800*620*1000 | 1150*850*1100 |
Model | DLSB-50EX/10 | DLSB-50EX/20 | DLSB-50EX/30 | DLSB-50EX/40 | DLSB-50EX/60 | DLSB-50EX/80 | DLSB-50EX/120 |
Volume | 50L | ||||||
Min temperature | -15℃ | -24℃ | -33℃ | -42℃ | -62℃ | -82℃ | -123℃ |
Cooling capacity | 1328-319W | 1328-319W | 2733-627W | 2036-602W | 2036-330W | 2036-180W | 3888-160W |
Flow capacity | 30L/min | ||||||
Head | 10-12M | ||||||
Temperature range | -10℃ | -20℃ | -30℃ | -40℃ | -60℃ | -80℃ | -120℃ |
Temperature accuracy | ±0.2 | ||||||
Voltage | 380V | ||||||
Working Temperature | 25℃ | ||||||
Working Humidity | (60-80)% ventilation | ||||||
Size(L*W*H) (mm) | 650*550*950 | 650*550*950 | 700*600*980 | 700*600*980 | 900*700*1140 | 900*700*1140 | 1270*900*1140 |
