What is a three-layer glass reactor?
The function of a three-layer glass reactor is the same as that of a single-layer and double-layer one. They are all material synthesis instruments in the fields of chemistry, petroleum, chemical industry, biopharmaceuticals, etc., and can be used for distillation, concentration, reflux, separation, purification and other reactions under constant speed, constant force and constant temperature. The three-layer glass reactor is improved on the basis of the double-layer glass reactor. From the appearance, the three-layer glass reactor is not much different from the double-layer glass reactor. The main difference is that the reactor body has an extra layer of glass.
What is the working principle of a three-layer glass reactor?
The body of the three-layer glass reactor consists of two sets of interlayers composed of three layers of glass, which can provide stirring function and control the evaporation and reflux of the reaction solution. The inner interlayer of the three-layer glass reactor is used for heating or cooling, and the outer interlayer is used for vacuuming. The temperature of cooling or heating of the material in the reactor can be kept as much as possible under the vacuum state of the outer interlayer. The material reacts in the reactor, and after the reaction, the material is discharged from the PTFE discharge port at the bottom of the reactor.
What are the advantages of the three-layer glass reactor?
1. The three-layer glass reactor is sealed with polytetrafluoroethylene material and special rubber composite sealing ring. It can withstand various solvents and maintain high vacuum.
2. The three-layer glass reactor uses a condenser to increase the high recovery rate.
3. The standardized connection method is convenient for disassembly.
4. The three-layer glass reactor is equipped with a discharge switch, and the solvent recovery is very fast.
5. A vacuum gauge is available to select the appropriate working vacuum for low-boiling point materials.
6. The three-layer glass reactor is made of high-quality stainless steel, aluminum alloy, and new synthetic materials, which have the advantages of corrosion resistance, rust resistance, and resistance to various solvents.
7. The glass parts are made of high-temperature resistant borosilicate glass material with good physical and chemical properties.
8. The three-layer glass design ensures high vacuum in the experiment.
9. Electronic stepless speed regulation, spark-free motor, safe and reliable, and long life.
