SPECIFICATIONS
Model | LGY-5 | LGY-20 | LGY-50 | LGY-100 |
Matched glass reactor | 1-5L | 10-20L | 30-50L | 80-100L |
Material | 304 stainless steel | 304 stainless steel | 304 stainless steel | 304 stainless steel |
Volume(L) | 12 | 28 | 50 | 71 |
Pump power(W) | 40 | 120 | 120 | 120 |
Heating power(KW) | 2 | 3 | 5 | 8 |
Voltage | 220V/50Hz | 220V/50Hz | 220V/50Hz | 380V/50Hz |
Flow | 5-10L/min | |||
Lift head | 8-12m | |||
Connecting port size | 4# | 4# | 4# | 6# |
Connecting pipe | silicone tube | stainless steel bellows | stainless steel bellows | stainless steel bellows |
Temperature control mode | Intelligent temperature control | |||
Temperature display mode | K type sensor digital display | |||
Temperature range | 0-300℃ | 0-300℃ | 0-300℃ | 0-300℃ |
Temperature accuracy | ±1℃ | ±1℃ | ±1℃ | ±1℃ |
Inner size (mm*mm*mm) | ￠250*240 | 390*280*255 | 430*430*270 | 490*440*330 |
Overall size(mm*mm*mm) | 435*305*630 | 630*400*630 | 630*500*630 | 680*500*665 |
Packing size (mm*mm*mm) | 590*460*460 | 730*500*830 | 730*600*830 | 780*600*865 |
Gross weight（KG） | 16 | 33 | 36 | 40 |
