SPECIFICATIONS
Model | LGMD-60C | LGMD-80C | LGMD-100C | LGMD-150C | LGMD-200C | LGMD-230C |
Effective evaporation area (m²) | 0.06 | 0.1 | 0.15 | 0.24 | 0.35 | 0.5 |
Condensation area (m²) | 0.1 | 0.15 | 0.2 | 0.4 | 0.5 | 0.65 |
Inner diameter of barrel (mm) | 60 | 80 | 100 | 150 | 200 | 230 |
Feed tank capacity (L) | 1 | 1.5 | 2 | 2 | 5 | 5 |
Feeding speed g/hr | 250-500 | 500-750 | 750-1500 | 1500-3000 | 3000-5000 | 3000-6000 |
8-10 hours output | 1-3L | 2-5L | 3-8L | 6-15L | 10-20L | 20L-30L |
Motor | 120 | 120 | 120 | 120 | 200 | 200 |
Maximum speed (rpm) | 450 | 450 | 450 | 450 | 300 | 300 |
Distillation collection bottle | 1L | 1L | 2L | 3L | 5L | 5L |
Residue collection bottle | 1L | 1L | 2L | 3L | 5L | 5L |
Processing flow (kg/H) | 0.1-2.0 | 0.3-4.0 | 0.5-5.0 | 1.0-8.0 | 1.5-10.0 | 2.0-15.0 |
Voltage | 220V 50HZ | |||||
Operating temperature | 90℃-200℃ | |||||
